Brand: Blackmagic Design

Dimensione effettiva del sensore
36mm x 24mm (Full Frame)

Attacco obiettivo
Active L-Mount.

Controllo obiettivo
Iris and focus on supported lenses.

Gamma dinamica
13 Stops.

Doppio ISO nativo
400 and 3200

Risoluzioni di ripresa
6048 x 4032 (Open Gate 3:2) fino a 36 fps
4832 x 4032 (Anamorphic 6:5) fino a 36 fps
6048 x 3200 (6K DCI 17:9) fino a 48 fps
6048 x 2520 (6K 2.4:1) fino a 60 fps
4096 x 3072 (Super 35 4:3) fino a 50 fps
4096 x 2160 (4K DCI 17:9) fino a 60 fps
2112 x 1184 (Super 16 16:9) fino a 100 fps
1920 x 1080 (1080 HD 16:9) fino a 120 fps

Frame rate
Maximum sensor frame rate dependent on resolution and codec selected. Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps supported.
Off-speed frame rates up to 60 fps in 6K 2.4:1 and 4K DCI 17:9, 100 fps in Super 16 16:9 and 120 fps in 1080HD.

Messa a fuoco
Auto focus available using compatible lenses.

Diaframma
Iris wheel and touchscreen slider for manual iris adjustment on electronically controllable lenses, iris button for instant auto iris settings on compatible lenses.

Dimensioni display
4” 1920 x 1080

Luminosità display
1500 nits

Tipo display
LCD capacitive touchscreen.

Supporto per metadati
Automatically populated lens data from electronic L-Mount lenses. Automatic recording of camera settings, motion sensor data plus slate data such as project, scene number, take and special notes. A 3D LUT can also be embedded in metadata of Blackmagic RAW files.

Controlli
Touchscreen menus on 4 inch screen. 1 x Power Switch, 1 x Record Button, 1 x Stills Button, 1 x Scroll Wheel with push, 1 x ISO Button, 1 x White Balance, 1 x Shutter Button, 3 x software configurable Fn buttons, 1 x Focus Button, 1 x IRIS Button, 1 x High Frame Rate (HFR) Button, 1 x Zoom Button, 1 x Menu Button, 1 x Playback Button, 1 x Next Clip Button, 1 x Previous Clip Button, 1 x Lock Switch.

Timecode
Highly accurate timecode clock. Less than 1 frame drift every 8 hours.
